Innosteelix provides comprehensive structural steel detailing services that transform design intent into constructible, shop-ready deliverables. With over 15 years of experience, our team produces precise drawings for fabrication, erection, and coordination — helping fabricators, contractors, and engineers build better with clarity and confidence.
Scope: Architectural Misc. Detailing
Full-service drafting, full rendered layouts, connection drawings, BOM.
All outputs are reviewed through a quality control checklist to ensure dimensional accuracy, field-friendliness, and compliance with project specifications.
We work with industry-leading platforms and deliver outputs in multiple formats:
All detailing is done in strict alignment with:
We maintain consistency in detail, structure, and drawing output using software and practices aligned with global standards.
American Institute of Steel
Construction (AISC)
Canadian Institute of Steel
Construction (CISC)
We are dedicated to delivering zero-error detailing ready for CNC processing and site execution.
Whether you’re a fabricator, engineer, or project manager — we’re ready to collaborate.
