Our Detailing Process – From RFQ to Fabrication-Ready Drawings

At Innosteelix, we follow a structured, quality-driven process that ensures smooth execution, timely delivery, and accurate documentation for every project. Whether it’s a basic framing job or a complex industrial structure, our approach is designed to minimize delays, maintain control, and keep your projects on track.

Our Standard Detailing Workflow

requirement-gathering

Requirement Gathering & Scope Review

  • Receive RFQ, drawings, models, and project specs
  • Understand scope, codes, file formats, and deadlines
  • Clarify missing inputs and confirm deliverables
requirement-gathering

Estimation & Timeline Proposal

  • Project man-hour estimation
  • Submission of quote with timeline and milestone planning
  • Project kick-off upon client approval
requirement-gathering

Modeling & Drafting Initiation

  • Begin 3D modeling of main members (columns, beams, braces)
  • Develop base layout and framing structure
  • Incorporate anchor bolts, plates, and embedded elements
requirement-gathering

Connection Design & Detailing

  • Create/verify connection details as per load inputs or standard library
  • Draft shop drawings with field annotations and fabricator standards
requirement-gathering

Internal Checking & QC

  • Run internal checks on geometry, dimensions, BOM, and constructability
  • Peer review by senior checker or lead engineer
  • Corrections and iterations logged
requirement-gathering

Client Review & Feedback

  • Submit first lot for client review
  • Receive mark-ups and suggestions
  • Revisions incorporated promptly with change log
requirement-gathering

Final Submission

  • Submit final shop and erection drawings, BOM, CNC files (NC1, KSS, DXF)
  • Label all revisions clearly
  • Upload via secure FTP or client’s shared drive
requirement-gathering

Post-Delivery Support

  • Assist with RFI resolutions, consultant comments
  • Provide record drawings and revision control documents
  • Support fabrication or field teams as needed

Let’s Discuss Your Next Project

Whether you’re a fabricator, engineer, or project manager — we’re ready to collaborate.
